44
Maintenance
Transporting
Pushing Machine
The machine may be pushed for short distances at
speeds not to exceed 5 mph. Be careful to avoid
damaging machine. The machine may be pushed by
hand from the rear.
NOTE: To avoid damage caused by regenerative
voltage, disconnect traction motor before towing or
pushing machine.
Machine Tie-Downs
There are four tie down points, two on the front wheel
guards, and two on the rear axle located on either side
of the foot box.
Trailer Loading/Unloading
Brush deck must be in the up position before loading.
Once loaded, lower brush deck, turn off machine, and
ensure brake is engaged. Block the tires to prevent the
machine from rolling and tie down machine using
indicated anchor points.
Reverse process to unload.
8.641-374.0 operator’s manual - chariot 3 - cv86/1 rs bp
Tie down point
Tie down point
Wheel Guards
Rear Axle
(Both sides)
(Both sides)
