13
Operations
Components
1.
Control Panel - Drive
2.
Control Pane
l - V
acuum
3.
Pedal Platform
4.
Rear Cover
5.
Cover
6.
Cover Lid
7.
Brush De
ck
8.
V
acuum Bag
9.
Side Broom
8.641-374.0 opera
tor
’s manual - chariot 3 -
cv86/1 rs bp
1
2
3
4
5
6
7
8
9
UNDER LID
12
14
