36
Maintenance
Brush Deck
1. Brush Deck
2. Brush Release Clips
3. Brush Motor
4. Brush Deck Lift Actuator
5. Side Broom
2
2
5
4
3
2
1
8.641-374.0 operator’s manual - chariot 3 - cv86/1 rs bp
