4-3
SECTION 4 –
APPLIANCES AND SYSTEMS
NOTE: A water shut-off valve for the ice maker
is located near the water faucet filter
inside the galley cabinet beneath the
sink.
Further Information
See the refrigerator manufacturer’s operation,
care and maintenance information in your
InfoCase.
REFRIGERATOR SERVICE
ACCESS COMPARTMENT
(Exterior)
The exterior refrigerator service compartment
allows access to the rear of the refrigerator for
inspection, maintenance and service.
To Open:
1. Use a screwdriver or coin to turn the latch
knobs to the vertical position as shown.
2. Remove the door from the opening.
To Close:
1. Replace the door into the opening.
2. Push the latch knobs in while turning to the
horizontal position as shown.
REFRIGERATOR/FREEZER -
PORTABLE
-If Equipped
Your coach may be equipped with a 120-volt
AC/12-volt DC portable refrigerator/freezer,
which is mounted on a slide tray in a passenger
side storage compartment.
• To pull out the refrigerator/freezer unit for
easier access, pull up on the locking
mechanism (located on the bottom left) to
release slide tray.
• Pull the slide tray out.
Refrigerator Access Door Latches
Refrigerator Access Compartment
