SECTION 3 –
DRIVING YOUR MOTOR HOME
3-8
REARVIEW MONITOR SYSTEM
–If Equipped
The rearview camera monitor system lets you
see what is directly behind your coach for
maneuvering assistance and safety.
A microphone built into the rear camera lets
you hear warning sounds or verbal directions
from an assistant.
Basic Operating Instructions
Sideview Cameras
–If Equipped
The optional sideview cameras allow you to
see what is beside you before turning or changing
lanes.
The sideview cameras activate with the
corresponding turn signals and replace the rear
camera view on the monitor until the turn is
completed or the signal lever is canceled
manually.
Further Information
See the rearview monitor manufacturer’s
complete operating information in your
InfoCase.
Mirror Arm Pivot Bolt
on underside of mounting base
- Shown with access plug removed
(Torque nut to 75-100 in./lbs.)
Power
• Turn ON to activate monitor for rear viewing
while driving or parked. Key must be on.
• In OFF (Standby) position the monitor is
“asleep” and will “wake up” when the
transmission is shifted into reverse.
Menu
• Each one press less than 1 second enters
brightness, contrast, color, or tint adjust mode.
(Time out of menu is approximately 5 seconds from
last key pressed.)
• Press menu button over 2 seconds to enter
setup menu.
(Press again before time out exits menu mode.)
Select
• Pressing the “Select” button sequences source
input modes from Ch1, to Ch2, to Ch3.
Up/Down
• Pressing UP increases brightness, contrast,
color, or tint level.
• Pressing DN decreases brightness, contrast,
color, or tint level.
Day/Night
• Pressing DAY/NIGHT button sequences day/
night backlight compensation through DAY,
NIGHT, and AUTO modes.
Volume +/-
• Pressing “+” button increases speaker volume.
• Pressing “-” decreases speaker volume.
To Next Page
