Winnebago Sunstar - Water Heater Bypass Valve

7-7
SECTION 7 -
PLUMBING
WATER HEATER BYPASS
VALVE
Your coach may be equipped with a water
heater bypass valve for easier winterization of
water lines using RV antifreeze. See table at the
end of this section for valve location.
Turn the handle as shown to either bypass or
flow through the water heater.
DRAIN
DRAIN
CLOSE
CLOSE
IN-LINE
VALVE
LINE-END
VALVE
Water Line Drain Valve
(Typical)
Water Tank Drain Valve (Typical)
Water Heater Bypass Valve (Typical)
Siphon
Tube
Winterizing
Tube
Winterization Valve beneath rear bed
Model 30B shown
Normal
Flow
By-Pass
Mode
