SECTION 9 -
FURNITURE AND SOFTGOODS
9-2
DINETTE/BED CONVERSION
–If Equipped
(Typical view – your coach may differ)
Dinette to Bed:
1. Release the catch on the table leg brace and
fold the leg up against the bottom of the table.
2. Remove the table from the wall support
bracket by lifting the end of the table. Then
lower the table to rest on the cleats attached to
each dinette bench.
3. Arrange dinette cushions to cover bed area.
Bed to Dinette:
1. Reattach the table onto the wall support and
lower the table leg.
2. Make sure that the table leg is secured into the
floor support bracket and the leg brace is
locked.
Table
Bracket
Wall
Support
To Next Page
