12-7
SECTION 12 –
MISCELLANEOUS
The step has several automatic extend/retract
functions that are controlled by the position of a
sensor mounted on the inner edge (hinge side) of
the screen door.
Automatic Mode - Entry Step
Switch ON
(Step Operates with Door)
With the Step switch in the ON position, the
step is in Automatic Mode. This means it will
extend and retract automatically whenever the
screen door is opened or closed.
Stationary Extended Mode - Step
Switch OFF
(Step Remains Extended)
With the Step power switch in the OFF
position, the step will extend when the screen
door is opened and will stay extended whether
the door is opened or closed.
This position is normally used to keep the step
extended when parked at a campsite or whenever
people will be going in and out the vehicle
frequently.
Automatic Retraction Feature
The step is equipped with an automatic
retraction feature that stores the step
automatically if the main entry door is closed and
when the chassis transmission is taken out of
park.
The step WILL RETRACT even if the Step
switch is OFF.
This feature is intended to prevent injury or
damage by an extended step while the vehicle is
moving.
Further Information
For additional information on the step, see the
manufacturer’s operators manual included in
your InfoCase.
WINDOWS
Crank-Out Windows
–If Equipped
• To open, pull out the lever on the window
handle and begin cranking the window out
“counter-clockwise” to desired position.
Entry Step Switch
(Located near entrance door)
-Typical View
Red Activation Lever
• The red Activation Lever located on the entry
step switch must be depressed in order to put
the step switch in the ON position.
To Next Page
