2-13
SECTION 2 –
SAFETY AND PRECAUTIONS
Under the front cover is the chassis supplied
black center cover. The recessed area has three
alternating silver washers. Removal of the three
nuts on top of the three washers will allow the
removal of the center cover while the wheel is
still retained to the hub with the remaining three
nuts.
When re-installing the front liner, make sure
to align the stem clearance notch on the back of
the liner with the valve stem.
When installing the liner, be sure it is engaged
all around the perimeter (outside edge) equally.
Note: If the edge on one side is pushed in before
the other, it may be difficult to complete
the push on procedure.
Further Information
See the chassis manufacturer’s user guide
provided in your InfoCase for complete
instructions and re-torque information.
WHEELS – STYLIZED
POLISHED
(Mercedes-Benz
®
Sprinter Chassis)
–If Equipped
The stylized wheel on your coach has bright
(chrome) lug nuts and washers. Because the hex
on the specialized lug nut is larger than the
chassis supplied lug wrench, an adapter is
provided (stored with the lug wrench) to tighten
or remove the bright (chrome) lug nuts.
Valve Stem Clearance Notch
Valve Stem Clearance Notch aligned to Valve
Stem
Clearance Notch
Valve Stem
Chassis Supplied Wheel and Center Cover
If the notch is not aligned with the valve
stem, the valve stem may be damaged
which could deflate the tire causing
steering or handling problems.
DO NOT operate the vehicle with less
than all 6 nuts installed and properly
torqued.
