SECTION 7 –
PLUMBING
7-24
24J Waterlines
Two (2) valves located in water service center.
Water Tank
One (1) valve located in water service center.
Water Heater Water Heater with Tank - Drain plug on outside of coach
behind service door. Use socket to remove drain plug.
Tankless Water Heater - Drain from outside of coach behind
service door. Pull down on the Easy Drain Lever and remove
the Water Inlet Filter.
Winerization
Valve 1
Water Heater Bypass Valve - Access by lifting the forward
section of rear bed board.
Winterization
Valve 3
Hot Water Recirculation Line Drain Valve for Tankless
Water Heater Only -
Access by lifting the forward section
of rear bed board.
Winterization
Valve 2
Winterization (Antifreeze) Valve - Located in water
service center (turn Winterization Valve 2 to “Winterize”
position.
24V Waterlines
Two (2) valves located in water service center.
Water Tank
One (1) valve located in water service center.
Water Heater Water Heater with Tank - Drain plug on outside of coach
behind service door. Use socket to remove drain plug.
Tankless Water Heater - Drain from outside of coach behind
service door. Pull down on the Easy Drain Lever and remove
the Water Inlet Filter.
Winerization
Valve 1
Water Heater Bypass Valve - Access panel located on
driver side rear bed adjustable headrest.
Winterization
Valve 3
Hot Water Recirculation Line Drain Valve for Tankless
Water Heater Only -
Access panel located on driver side
rear bed adjustable headrest.
Winterization
Valve 2
Winterization (Antifreeze) Valve - Access panel located
on driver side rear bed adjustable headrest.
