Pre-wash zone
The pre-wash zone is used for scraping residue off the wash items.
840 mm 350 mm
1 22 3 4 5 4 16
Item Pre-wash zone 840mm Pre-wash zone 350mm
1 Rack conveyor with push bars Rack conveyor with push bars
2 Wash arms Wash arms
3 Strainer -
4 Curtain -
5 Door -
6 Tank -
Air knife drying zone (optional)
41 2 3
In the air knife drying zone, water is removed from recesses
in the wash items by means of a stream of air from above.
Item Name
1 Air tray
2 Ventilator jet
3 Door
4 Rack conveyor with push bars
