3.6 Info menu
Display of temperatures
1 2 3 4 5 7 96 5 8
Item Name
1 Access to the warewashing staff menu / chef menu
2 Tab for temperature of pre-wash zone
3 Tab for temperature of main wash zones
4 Tank temperature of each zone
5 Tab for temperature of rinse zone
6 Tab for temperature of drying zones and air knife drying zones (display of each zone)
7 Tank temperature of rinse zone
8 Rinse water temperature
9 Switch to the next info display
Display of warewasher data
1
2
4
6
7
8
53
Item Name Item Name
1 Access to the warewashing staff menu / chef
menu
5 Date / time
2 Hygiene check (in case of fault) 6 CONNECTED WASH (optional)
3 Machine number 7 Telephone number for service technician and
chemical supplier
4 Display area for error pictograms 8 Machine model
