2.2 Use
CAUTION! Make sure the area around the air heater is
dry when performing maintenance on the air heater.
CAUTION! Always close the doors and inspection hatches
of the air heater, except when adjusting and checking the
appliance.
2.3 Maintenance & Cleaning
Frequent maintenance and cleaning of the air heater is
necessary to ensure safe and proper operation. Failure
to do so could lead to damage to the heater or its
surroundings and void the warranty.
2.3.1 Protection from water (IP class)
WARNING! Never use water when cleaning electrical
parts.
This air heater is not waterproof and has an IP00B
classification.
WARNING! Do not expose the air heater to rain, spray or
dripping water.
2.4 Children and vulnerable users
WARNING! This air heater can be used by children aged
8 years and above and by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge, if they are supervised or instructed concerning
use of the appliance in a safe way and understand the
hazards involved.
WARNING! Children shall not play with the air heater.
WARNING! Children shall not clean and maintain this air
heater without supervision.
3 Technical specifications
3.1 Performance
Technical specification Unit Type XR-4.1 (ERP2018)
XR10 XR20 XR30 XR40 XR50 XR60
Net nominal heat input (max.) kW 14.0 22.8 32.0 44.0 55.0 66.0
Net nominal heat input (min.) kW 9.0 14.8 20.5 26.4 33.0 39.6
Heat output (max.) kW 12.8 20.8 29.2 40.2 49.9 60.5
Heat output (min.) kW 8.3 13.8 19.1 24.4 30.8 37.0
Eciency at max. power % 91.4 91.3 91.1 91.4 90.7 91.7
Eciency at min. power % 91.7 93.0 93.1 92.4 93.3 93.4
Air output (max.) m
3
/h 1150 2070 2600 4370 5150 6300
Throw horizontal (max.) m 12 16 23 26 28 30
Throw vertical (max. warm) m 5 5 6 7 7 8
Gas connection G” 1/2" 1/2" 1/2" 3/4" 3/4" 3/4"
Electrical connection (50 Hz) V 230 230 230 230 230 230
Electrical power consumption
(max.)
kW 0.250 0.250 0.250 0.450 0.450 0.600
Electrical power consumption
(min.)
kW 0.250 0.250 0.250 0.450 0.450 0.600
Stand-by electrical power
consumption
kW 0.004 0.004 0.004 0.004 0.004 0.004
Electrical current A 1.1 1.1 1.1 2.0 2.0 2.6
Protection class - IP00B
