Wintriss SmartPAC User Manual

1145200 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO
10 Instruction Sheet
SmartPAC 2

SmartPAC PRO RTS
Signal Type
Connector
Pin
number
Connector
Pin
number
Done

WPC Adjustment Lockout Switch (Optional)
GRD.
TB107
250

TB5
247
Lockout
TB107
251

TB5
251
Remote Reset (Optional)
GRD.
TB107
250

TB5
247
Remote Res.
TB107
249

TB5
249
AutoSetPAC / WaveFormPAC 2 or 4 Channel (Optional)
GRD.
TB103
240

TB6
240
+RXD2
TB103
241

TB6
241
-RXD2
TB103
242

TB6
242
+TXD2
TB103
243

TB6
243
-TXD2
TB103
244

TB6
244
SFI (Optional)
+RXD1
TB103
235

TB6
235
-RXD1
TB103
236

TB6
236
TXD1
TB103
237

TB6
237
+TXD1
TB103
238

TB6
238
-TXD1
TB103
239

TB6
239
GRD
TB103
240

TB6
240
