Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200
Instruction Sheet 9
SmartPAC 2
SmartPAC PRO RTS
Signal Type
Connector
Pin
number
Connector
Pin
number
Done
Resolver Port
S1
TB101
213
TB3
213
S2
TB101
214
TB3
214
R1
TB101
215
TB3
215
S3
TB101
216
TB3
216
R2
TB101
217
TB3
217
S4
TB101
218
TB3
218
Shield
TB101
212
TB3
212
Position Sensor (if used)
+V
TB107
245
TB5
245
POS.
TB107
246
TB5
246
GRD.
TB107
247
TB5
247
WPC Port ( Integration only)
+RXD
TB105
327
TB8
327
-RXD
TB105
328
TB8
328
+TXD
TB105
329
TB8
329
-TXD
TB105
330
TB8
330
GRD.
TB105
326
TB8
326
Remote Dual Op Station Select (Optional Remote Reset Switch)
GRD.
TB107
256
TB5
Rem rest
TB107
257
TB5
249
Op Sta. 1
TB107
254
TB2 HMI
Bd 4
24vdc
Op Sta. 2
TB107
253
TB2 HMI
Bd 3
24vdc
