WPS-100-DVR-4CH Installation and Users Manual
2.3 REMOTE CONTROL
Remote Control Buttons include:
1. 1-9, 0, *, # (Numeric Buttons)
3. CALL Button
4. MODE Button
5. +/- buttons by the
/ symbol (Volume/Zoom Control)
6. +/- Buttons by the
symbol (Split Window Control)
7. ENTER Button
8. MENU / ESC Button
9.S/BS (Up/BS Button)
10. PTZ ( No Function on 4ch)
11.W X(Left/Right Buttons)
13. FWD/REV (on the jog shuttle dial)
14.
(Copy Button)
15. X/II (Play/Pause Button)
16. (Stop Button)
18. X2/GOTO
20. T/DEL (Down/DEL Button)
22. MUTE/NEXT
24. SEQ Button
25. SEARCH Button
26. Alarm Reset
27. REC Button
