3. Carefully guide the clamping jaw (Fig. 13/1) to the watch
or the watch movement.
ð
• The complete watch or the watch movement with
cup is clamped.
• The LED on the device (Fig. 13/2) flashes at the
same frequency as the watch beats.
• The measuring process starts automatically
(Fig. 14).
Alternatively, the measurement can be started using
the “Restart” button in the display software.
Information in the software manual
Information on the measuring process and on
controlling the measurement is to be found in
the corresponding software manual.
Fig. 12: Clamping the watch move-
ment with cup
Fig. 13: Releasing the clamping jaw
Fig. 14: The measuring process
starts automatically
24.03.2021 Precision measuring device ChronoMaster / ChronoMaster Air 31
