Door Drive
MIDI / SUPRA
Operating instructions
Blatt/
sheet
D823MGB.009
Datum/
date
01.03.2004
Stand/
version
B-18.12.2008
Geprüft/
approved
WAT/MZE
EXCELLENCE IN COMPONENTS
Änderungen vorbehalten! Subject to change without notice!
6 Electrical Interfaces
6.1 Inputs
The Inputs are activated if they are switched at
COM.
Name of the ter-
minal
Symbol
Terminal
Explanation
COM COM
COMMON
Common line for I 1..4
I1
OPEN
This command will drive the door in open direction until
the open position is reached. Depending on the setting of
DIP switch S1/8 the door is kept open by motor torque
also without command.
I2
CLOSE
This command will drive the door in close direction until
close position is reached and coupler is opened. Depending
on the setting of DIP switch S1/8 the door is kept closed
by motor torque also without command
I3
NDG
NUDGING
Nudging input, puts the door to slow speed drive in close
direction. Smoke sensitive devices like photo cell or light
barrier (Input IPD) will be ignored.
I4
RSH
HIGH SPEED
By setting this input a higher speed can be selected. This
input is active only when DIP switch S1/6 is switched OFF.
I5
EO
EMERCENY OPEN
The door opens if this input is set during the door is supp-
lied by a emergency battery (terminal X5 BATT) and no line
supply is available any more.
