Field Name Description
Dial Plan If or not enable dial plan.
Line Set the line.
Digit Map Fill in the sequence used to match input number
The syntactic, please refer to the following Dial Plan Syntactic
Action Choose the dial plan mode from Deny and Dial Out.
Deny means WB100A will reject the matched number, while Dial
Out means WB100A will dial out the matched number.
Move Up Press it to move up.
Move Down Press it to move down.
2) Adding one dial plan:
 Enable Dial Plan
 Click Add button, and the configuration table
 Fill in the value of parameters.
 Press OK button to end configuration.
 Press Save button to save changes

3) Dial Plan Syntactic
No. String Description
1 0 1 2 3 4 5 6 7 8 9 * # Legal characters
2 x Lowercase letter x stands for one legal character
3 [sequence] To match one character form sequence.
For example:
• [0-9]: match one digit form 0 to 9
• [23-5*]: match one character from 2 or 3 or 4
or 5 or *
4 x. Match to , , , …...
For example:
“01.”:can match ”0”, “01”,
“011”, ”0111”, …….., ”01111…”
5 <dialed:substituted> Replace dialed with substituted.
For example：
<8:1650>123456 ： input is “85551212”, output
is“16505551212”
6 x,y Make outside dial tone after dialing “x”, stop until
dialing character “y”
For example：
“9,1xxxxxxxxxx”:the device reports dial tone after
inputting “9”, stops tone until inputting “1”
“9,8,010x”: make outside dial tone after inputting
“9”, stop tone until inputting “0”
7 T Set the delayed time.
For example:
