WMF 5000 S+ - Appendix: Technical Data; Technical Data for Coffee Machine

112
User Manual WMF5000S +
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 12.8in (325mm)
Height 28.19in (716mm) (with lockablebean hopper)
Depth 23.23in (590mm)
Coffee bean hopper approx. 38.80oz (1,100g) per load
(1
Coffee bean hopper in the center
approx.24.69oz(700g)
(1
Powder hopper (optional) approx. 70.55oz (2,000g)
(2
Weight empty approx. 81.57lb (37kg) (depending on the model)
Water supply 3/8inch hose connector with water mains tap, and
dirt filter with 0.003in (0.08mm) mesh size, on-site.
(3
At least 29psi (0.2MPa) (2bar) supply pressure at
0.53gal/min (2l/min).
Maximum 87psi (0.6MPa) (6bar).
Maximum inlet temperature 95°F (35°C).
The set of hoses provided with the new coffee
machine and/or the new water filter must be used.
Donot use the old set of hoses.
Water quality For drinking water with carbonate hardness from
5°dKH (5gpg) or higher, aWMFwater filter must be
fitted.
Water drain tube
(optional)
Hose aminimum of DN 19, minimum downward slope
of 0.02in/in (2cm/m)
Use at elevation above
sea level
< 6,562ft
We reserve the right to make technical modifications.
(1
The capacity depends on the size of the coffee beans.
(2
Only with optional powder hopper. The capacity depends on the powder used.
(3
These specifications (IEC60335–2-75) for the water connection to the coffee
machine apply in EU member states. It may be necessary to also observe
additional country-specific regulations. Outside the EU countries acceptance of
the standards quoted is to be checked by the legal entity or natural person who
wishes to use the coffee machine.
