User Manual WMF950S
Appendix: Technical data
Appendix: Technical data
External dimensions Width 303mm
Depth 528mm
Height 562mm
Weight empty 22kg
Water supply 3/8inch hose connector with water mains tap,
and dirt filter with 0.08mm mesh size, on-site.
(1
At least 0.2MPa (2bar) supply pressure at2l/min.
Maximum 0.6MPa (6bar).
Important.
If the customer’s on-site flow pressure exceeds
0.6MPa (6bar), then apressure reducer must
absolutely be connected upstream and set to
amaximum of 0.6MPa (6bar).
Maximum inlet temperature 35°C.
The set of hoses provided with the new coffee
machine, the permanent water connection kit, or
the new water filter must be used. Do not use the
old set of hoses.
Water quality For drinking water with carbonate hardness from
5°dKH or higher, aWMFwater filter must be
fitted.
Water tank volumes approx. 1.8l
Use at elevation above sea
level
< 2,000m
Nominal power rating 2.6–2.8kW
Power supply 220–240V, 50/60Hz, (1/N/PE)
Illumination LED class 1
Degree of protection IP X0
Protection class
Continuous sound pressure
level (Lpa)
< 70dB(A)
(2
We reserve the right to make technical modifications.
(1
These specifications (IEC60335–2-75) for the water connection to the coffee machine apply in EU member states. It
may be necessary to also observe additional country-specific regulations. Outside the EU countries acceptance of the
standards quoted is to be checked by the legal entity or natural person who wishes to use the coffee machine.
(2
A-evaluated sound pressure level Lpa (slow) and Lpa (impulses) at operating personnel workplace is under 70dB(A) in any
working mode.
