Adjust the throttle wire rope by turning the adjusting nut
to achieve the correct free stroke of the throttle handle.
1. When the free stroke of the throttle handle is greater
than or less than the standard value, it needs to be
readjusted.
2. Adjustment method for free stroke of throttle wire cable:
loosen the locking nut, turn in or out the adjusting nut
until the specified free stroke is reached, and tighten the
locking nut.
2
1
Adjustment of accelerator cable
Standard value of throttle handle: 2mm ~ 6mm
In case of interference and wear of throttle steel wire
cable, the acceleration handle and steel wire cable must
be removed for cleaning or replacement, and lubricating
grease shall be added.
