Wolf CGB-2 - Ionisation and Ignition Electrode Checks; Electrode Replacement and Calibration

3064812_201804 17
12.Checkingtheionisationandignition
electrodes
Repacingtheignitionelectrode
Replace ignition electrode with every maintenance.
Check spacings and adapt if not correct.
Replacingtheionisationelectrode
Replace ionisation electrode with every maintenance.
Tighten the electrode xing screws with a torque of
3,0 Nm.!
Carry out a 100 % calibration after working on
the ionisation electrode.
See description HG43 in chapter
“Parameter description” in the installation
instructions.
Fig.: Ionisation electrode gap
Fig.: Ignition electrode gap
