Wolf FGB-28 - Page 42

42
3064458_201811
20 15 10 50-5 -10 -15 -20
20
30
40
50
60
70
80
90
100
12
Outside temperature [°C]
Heating curve
Sample setting:
Temperature correction: +4
H08 - (ow, max. heating operation)
75 °C
H21 - (boiler, min. temperature) 20 °C
H54 - (heating curve) 12
Flow temperature [°C]
Temperature correction: +4
20 15 10 50-5 -10 -15 -20
20
30
40
50
60
70
80
90
100
12
Outside temperature [°C]
Heating curve
Sample setting:
Temperature correction: -4
H08 - (ow, max. heating operation)
75 °C
H21 - (boiler, min. temperature) 20 °C
H54 - (heating curve) 12
Flow temperature [°C]
Temperature correction: - 4
20 15 10 50-5 -10 -15 -20
20
30
40
50
60
70
80
90
100
12
Outside temperature [°C]
Heating curve
Sample setting:
Temperature correction: 0
H08 - (ow, max. heating operation)
75 °C
H21 - (boiler, min. temperature) 20 °C
H54 - (heating curve) 12
Flow temperature [°C]
Temperature correction: 0
Temperature selection -4...+4 for heating circuit
The ow temperature of the heating curve is changed with temperature selection -4...+4 as follows:
17. Parameter description
