Wood-mizer LT70 Series Operator's Manual

Parts List
Wireless Receiver Housing, DC Sawmills
4
4-3 doc021820 Parts List
4.5 Wireless Receiver Housing, DC Sawmills
REF. DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY
- HOUSING, DC WIRELESS RECEIVER 532248 1
1 BOX WELDMENT 530943-1 1
2 GASKET, CORK 532355 1
3 PLATE, FRONT 530945 1
4 PLATE, MOUNTING 532351-1 1
5 WASHER, 5.3 FLAT ZINC F81052-1 10
6 BOLT, #10-24X1/2 SELF-TAPPING F05015-7 10
7 SCREW, M4X16-5.8-B SLOTTED COUNTERSUNK HEAD ZINC F81011-4 2
8 NUT, M4-8 HEX NYLON ZINC LOCK F81029-1 2
9 GASKET, CORK 532366 1
10 SCREW, M6X10 BN 11252 "BOSSARD". F81001-57 4
11 SCREW, M6X16 8.8 HEX SOCKET HEAD CAP ZINC F81001-21 4
12 WASHER, 6.4 FLAT ZINC F81053-1 4
