Setup
Planer/moulder setup
3
3-5 doc050624 Setup
See table 3-1. Have a qualified electrician install the power supply (according to EN
60204 Standard). The power supply must meet the specifications given below.
IMPORTANT! It is recommended that a 30mA GFI (Ground
Fault Interrupter) be used.
IMPORTANT! When starting the machine for the first time,
check that main motor rotation direction is as indicated by
the arrow located on the motor body (fan guard). If the
rotation direction is incorrect invert the phases in the phase
inverter in the power socket box). Setting the phases in the
phase inverter correctly will ensure correct rotation
directions of all planer/moulder motors.
WARNING! In case of a drive belt break, wait until all
rotating parts are completely stop. Failure to do so may
result in serious injury or death.
DANGER! Use the inspection window to check cutter
rotation direction. To do it, look at the motor fan when
planer/moulder is turning on or off. Do not check the cutter
rotation direction by touching the cutter with any tool.
Failure to do so will result in serious injury of death.
Model Voltage Total power Total amperage
MP280EA12S-V 1X230V 14,05kW 83,5A
MP280EB13S-V 3X230V 17,75kW 60,9A
MP280EH13S-V 3X400V 17,75kW 34,7A
TABLE 3-1
To Next Page
