PLANER/MOULDER SPECIFICATIONS
Overall dimensions
PLANER/MOULDER SPECIFICATIONS doc050624 7-1
7
SECTION 7 PLANER/MOULDER SPECIFICATIONS
7.1 Overall dimensions
See figure 7-1. The overall dimensions of the MP280 Planer/moulder are shown below (all
dimensions in millimeters).
FIG. 7-1 MP280
3130 mm
1000 mm
1285 mm
1180 mm
315 mm
1390 mm
