PLANER/MOULDER SPECIFICATIONS
Specifications of the planer/moulder
7
7-4 doc050624 PLANER/MOULDER SPECIFICATIONS
7.2 Specifications of the planer/moulder
See table 7-2. Wood-Mizer MP280 planer/moulder nomenclature is given in the table below.
See table 7-3. See the table below for specifications of the MP280 planer/moulder motors.
Volts
MP280EA12S-V 1x230V
MP280EB13S-V 3x230V
MP280EH13S-V 3x400V
TABLE 7-2
MP280EH13S-V
-VUpper cutter
motor specifica-
tions
Lower cutter
motor specifica-
tions
Side, fixed cutter
motor specifica-
tions
Side, movable
cutter motor
specifications
Feed motor
specifications
Motor Type Electric Motor Electric Motor Electric Motor Electric Motor Electric Motor
Rated Voltage 3x400V 3x400V 3x400V 3x400V 3x400V
Rated motor revo-
lutions
2900 r.p.m. 2900 r.p.m. 2900 r.p.m. 2900 r.p.m. 2800 r.p.m.
Rated cutter revo-
lutions
6000 r.p.m. 6000 r.p.m. 6000 r.p.m. 6000 r.p.m. ---.
Rated power 4kW 3kW 3kW 3kW 0,75kW
Wood-Mizer Part # 537387 537386 537385 537385 532808
TABLE 7-3
MP280EB13S-V
Upper cutter
motor specifi-
cations
Lower cutter
motor specifi-
cations
Side, fixed
cutter motor
specifica-
tions
Side, mov-
able cutter
motor speci-
fications
Feed motor
specifica-
tions
Cur-
rent
(FL)
Cur-
rent
(LL)
SCCR
Motor Type Electric Motor Electric Motor Electric Motor Electric Motor Electric Motor 48,7 10,2 5kA
Rated Voltage 3x230V 3x230V 3x230V 3x230V 3x230V
Rated motor
revolutions
2900 r.p.m. 2900 r.p.m. 2900 r.p.m. 2900 r.p.m. 2780 r.p.m.
Rated cutter
revolutions
6000 r.p.m. 6000 r.p.m. 6000 r.p.m. 6000 r.p.m. ---.
Rated power 4kW 3kW 3kW 3kW 0,75kW
Wood-Mizer
Part #
537387 537386 537385 537385 532808
TABLE 7-3
