PLANER/MOULDER SPECIFICATIONS
Specifications of the planer/moulder
PLANER/MOULDER SPECIFICATIONS doc050624 7-5
7
See table 7-4. Feed rate
MP280EA12U-V
Upper cutter
motor specifi-
cations
Lower cutter
motor specifi-
cations
Side, fixed
cutter motor
specifications
Side, mov-
able cutter
motor specifi-
cations
Feed motor
specifica-
tions
Cur-
rent
(FL)
Cur-
rent
(LL)
SCCR
Motor Type Electric Motor Electric Motor Electric Motor Electric Motor Electric Motor 25 5,4 5kA
Rated Voltage 1x230V 1x230V 1x230V 1x230V 1x230V
Rated motor
revolutions
2900 r.p.m. 2900 r.p.m. 2900 r.p.m. 2900 r.p.m. 1700 r.p.m.
Rated cutter
revolutions
7100 r.p.m. 7100 r.p.m. 7100 r.p.m. 7100 r.p.m. ---.
Rated power 2,7kW 2,7kW 2,7kW 2,7kW 0,55kW
Wood-Mizer
Part #
533651 533651 533651 533651 592832
TABLE 7-3
Planer/moulder type MP280 with constant
feed speed
MP280 with adjustable
feed speed
Feed Speed 5 m/min 3-15 m/min
TABLE 7-4
