.50 Series Parts 35
MAN1246 (04/10/2018)
WING & CENTRE GEARBOX ASSEMBLY
REF QTY
Left Wing
540 & 1000
Right Wing
540 & 1000
Centre
540 Only
Centre
1000 Only
DESCRIPTION
A 1 1045870 1045869 1045868 1045871 Complete repair gearbox
1 1 57316 **57316 57315 1005317 Gear crown
2 1 NS NS NS NS Gearbox housing
3 1 57319 57319 57319 57319 Input shaft
4 1 57356 57356 57356 57356 Output shaft
5 1 57358 57358 57359 1005316 Gear pinion
6 2 39263 39263 39263 39263 Bearing cup & cone
7 2 39411 39411 39411 39411 Bearing cup & cone
8 1 57338 57338 57338 57338 Protective seal
9 1 * * * * Cotter pin 3/16 x 2
10 2 57320 57320 57320 57320 Snap ring 85 UNI7437
11 1 57321 57321 57321 57321 Snap ring 50 UNI7435
12 1 57471 57471 57471 57471 Shim 45.3 x 2.5
13 2 57471 57471 57471 57471 Shim 70.3 x 84.7
14 1 57329 57329 57329 57329 Castle nut M40 x 1.5P
15 1 39323 39323 39323 39323 Castle nut M30 x 2.0P
16 1 57471 57471 57471 57471 Shim 50.3 x 70.3
17 1 57471 57471 57471 57471 Shim 40.3 x 61.7 x 1
18 1 1045873 1045873 1045873 1045873 Oil seal 50 x 90 x 10
19 1 57318 57318 57318 57318 Oil seal 45 x 85 x 10
20 1 57371 57371 57371 57371 Cap
22 1 1045878 1045878 1045878 1045878 Top cover
23 6 * * * * M8 x 16 GR8.8 HHCS
24 1 1045872 1045872 1045872 1045872 Dipstick, 1/2 x 6.18
25 1 * * * * Cotter pin 1/4 x 2-1/4
26 1 1024670 1024670 1024670 1024670 Washer, 1.22 x 2.205 x .236
27 1 1005512 1005512 1005512 1005512 Gearbox repair kit (Includes items (6,
7, 8, 10, 11, 12, 13, 18, & 19)
28 1 1045877 1045877 1045877 1045877 Magnetic drain plug [
NOT SHOWN]
(low neck of housing)
* *
Crown gear placed on opposite
end of input shaft for right wing
* Standard hardware, obtain locally
NS Not Serviced
