Manual 26833 TecJet 52 Gen II
Woodward 26
EC-US-L1
120
Ohm
User Control
CAN High
CAN Low
CAN Common
TecJet
CAN Interface
R
S
X
V
CAN
Controller
P
Q
Isolated User Source ONLY
120
Ohm
Connect P and Q with a short
jumper if termination is
desired.
Non-Isolated User Source
(Input Power - is CAN
common connection)
120
Ohm
User Control
CAN High
CAN Low
TecJet
CAN Interface
R
S
X
V
CAN
Controller
P
Q
120
Ohm
Connect P and Q with a short
jumper if termination is
desired.
Figure 2-7. TecJet 52 CAN Wiring for Isolated/Non-Isolated Systems
