20V Li-Ion multi-purpose saw EN
12
Working mode adjustment
Position I worked as a jigsaw.
Position II worked as a
reciprocating saw.
NOTE: Select the blade best
suitable for the working mode
for better cutting performance
(special reciprocating saw blade
not included).
WARNING!
• To avoid being pinched,
keep hands away from the
hinge when changing positions.
• To avoid tool being turned on
accidentally, make sure keep
your hands away from the lock-
off button.
• Before operation, make sure
the pivot release button is
locked into position.
See Fig. B1-C4
ASSEMBLY
Replacing the saw blade
When using jig saw mode,
the blade teeth face outward
as shown in Fig. D1; while in
rep saw mode, the blade teeth
should face as shown in Fig. D3.
CAUTION: Keep your
hands away from the
lock-off button to prevent
switch actuation before making
any adjustments or removing
or installing attachments or
accessories.
See Fig. D1-D3
OPERATION
WARNING! Burn hazard. Do not touch the
blade immediately after use. Contact with the
blade may result in personal injury.
Switching On and Off
NOTE: For safety reasons the
On/Off switch of the machine
cannot be locked; it must
remain pressed during the
entire operation.
See Fig. E
Pendulum Function See Fig. F1, F2
Cutting
WARNING!
• Never hold the pivot
head when operating the tool.
• Never hold the motor cover
when operating the tool.
Always use a blade suited to the
material and material thickness
to be cut. Before cutting any
type of material, be sure it is
firmly anchored or clamped to
prevent slipping. Holding the
work by hand or against your
body leaves it unstable and may
lead to loss of control.
• Whenever possible, the saw
foot plate must be held firmly
against the material being
cut. This will prevent the saw
from jumping or vibrating and
minimize blade breakage.
See Fig. G1 – G3
LED Work Light See Fig. H
WORKING HINTS FOR YOUR
MULTI-PURPOSED SAW
If your power tool becomes too hot, run no-load
for 2-3 minutes to cool the motor. Avoid prolonged
usage at very low speeds.
Any movement of the material may affect the quality
of the cut. The blade cuts on the upward stroke and
may chip the uppermost surface.
Ensure your uppermost surface is a non-visible
surface when your work is finished.
MAINTENANCE
Your power tool requires no additional
lubrication or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through the
ventilation slots. This is normal and will not damage
your power tool.
