Worx WX550 User Manual

11
WX550 WX550.X
20V Li-Ion
multi-purpose saw
The declared vibration total value and the declared noise
emission value have been measured in accordance with a
standard test method and may be used for comparing one
tool with another.
The declared vibration total value and the declared
noise emission value may also be used in a preliminary
assessment of exposure.
WARNING: The vibration and noise emissions
during actual use of the power tool can differ
from the declared value depending on the ways in which
the tool is used especially what kind of workpiece is
processed dependant on the following examples and
other variations on how the tool is used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained.
The use of the correct accessory for the tool and
ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration and noise accessories are used.
And the tool is being used as intended by its design and
these instructions.
This tool may cause hand-arm vibration syndrome if
its use is not adequately managed.
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off and
when it is running idle but not actually doing the job. This
may significantly reduce the exposure level over the total
working period.
Helping to minimise your vibration and noise exposure
risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions
and keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti
vibration and noise accessories.
Plan your work schedule to spread any high vibration tool
use across a number of days.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction
book carefully.
INTENDED USE
The machine is 2 saws in 1 tool with rep saw and jig saw
function, intended for sawing wood, plastic, metal and
building materials while resting firmly on the workpiece. It is
suitable for straight and curved cuts.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the battery pack
See Fig. A1
Charging the battery pack See Fig. A2
Installing the battery pack See Fig. A3
Working mode adjustment
Position I worked as a jigsaw.
Position II worked as a reciprocating saw.
NOTE: Select the blade best suitable
for the working mode for better cutting
performance (special reciprocating saw
blade not included).
WARNING!
• To avoid being pinched, keep hands
away from the hinge when changing
positions.
• To avoid tool being turned on accidentally,
make sure keep your hands away from the
lock-off button.
• Before operation, make sure the pivot
release button is locked into position.
See Fig. B1
- C4
ASSEMBLY
Replacing the saw blade
When using jig saw mode, the blade teeth
face outward as shown in Fig. D1; while in
rep saw mode, the blade teeth should face
as shown in Fig. D3.
CAUTION: Keep your hands away
from the lock-off button to prevent
switch actuation before making any
adjustments or removing or installing
attachments or accessories.
See Fig.
D1-D3
OPERATION
WARNING! Burn hazard. Do not touch the blade
immediately after use. Contact with the blade may
result in personal injury.
Switching On and Off
NOTE: For safety reasons the On/Off
switch of the machine cannot be locked;
it must remain pressed during the entire
operation.
See Fig. E
Pendulum Function
See Fig.
F1, F2

Worx WX550 Specifications

General

Product color	Black, Orange
Built-in light	-
Adjustable speed	Yes
Number of blades	1
Included saw blade type	Metal saw blade
Number of batteries included	1 pc(s)
Idle stroke rate (max)	3000 spm
Idle stroke rate (min)	0 spm
Input power	- W
Power source	Battery
Charging time	60 min
Battery voltage	20 V
Battery capacity	2 Ah
Battery level indicator	No

Weight and Dimensions

Depth	165 mm
Width	257 mm
Height	127 mm
Weight	1900 g
