10-S4
M108S, WSM
CABIN
WINDSHIELD WIPER
W1066515
Symptom Probable Cause Solution
Reference
Page
Windshield Wiper
Does Not Operate
Fuse blown (Short-circuit, burnt component
inside motor or other part for operation)
Correct cause and
replace
–
Wiper motor defective (Broken armature, worn
motor brush or seized motor shaft)
Replace 10-S46, 47
Wiper switch defective Replace 10-S31
Foreign material interrupts movement of link
mechanism
Repair 10-S46
Wiper arm seized or rusted Lubricate or replace 10-S46
Windshield Wiper
Operating Speed Is
Too Low
Wiper motor defective (Short-circuit of motor
armature, worn motor brush or seized motor
shaft)
Replace 10-S46
Low battery voltage Recharge or replace –
Humming occurs on motor in arm operating
cycle due to seized arm shaft
Lubricate or replace 10-S46
Wiper switch contact improper Replace 10-S31
Windshield Wiper
Does Not Stop
Correctly
Wiper motor defective (Contaminated auto-
return contacts or improper contact due to
foreign matter)
Replace 10-S46
KiSC issued 05, 2012 A
