wsm M108S - 2 Servicing Specifications

10-S5
M108S, WSM
CABIN
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
A/C Compressor Magnet Clutch Airgap 0.30 to 0.65 mm
0.012 to 0.025 in.
–
Magnet Clutch Stator Coil Resistance 3.0 to 4.0 Ω –
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
22 to 28 psi
–
Pressure
(HI Pressure Side)
1.28 to 1.66 MPa
13.0 to 17.0 kgf/cm
2
185 to 241 psi
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Less than
approx. 0.196 MPa
2.00 kgf/cm
2
28.4 psi
–
Setting Pressure
(HI Pressure Side)
More than
approx. 3.14 MPa
32.0 kgf/cm
2
455 psi
–
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.40 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Front Wiper Rotating Speed 33 to 43 times/min. –
KiSC issued 05, 2012 A
