G-74
M108S, WSM
G GENERAL
10. IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA. Use with implements which are not sold or approved by KUBOTA and which exceed the maximum
specifications listed below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions
or failures of the tractor, damage to other property and injury to the operator or others. [Any malfunctions or failures
of the tractor resulting from use with improper implements are not covered by the warranty.]
• Implement size may vary depending on soil operating conditions.
Tread (max. width) Operating condition
Lower link max.
lifting capacity : W0
Front
Rear
IMPORTANT
Tractor with front
spacer option is not
approved for use
with front loader.
without spacer with spacer
1675 mm
(65.94 in.)
2035 mm
(80.12 in.)
2110 mm
(83.07 in.)
2700 kg
(5952 lbs)
Actual figures
Implement weight : W1
and / or size
Max. drawbar Load : W2
Trailer loading weight : W3
Max. capacity
As in the following list
(Shown on the next page)
800 kg (1760 lbs)
3000 kg (6614 lbs)
(without trailer brake)
13000 kg (28660 lbs)
(with trailer brake)
Lower link end max. loading weight.............W0
Implement weight........................................The implement's weight which can be put on the lower link : W1
Max. drawbar load.......................................W2
Trailer loading weight..................................The max. loading weight for trailer (without trailer's weight) : W3
To Next Page
