Quick Set-Up (from onboard keypad) cont.
STEP 3
To decrease the volume of the person you are speaking to rst press the
TALK
/ END
key. If you have a live telephone line, the phone will say “Please enter number to
be dialed” and then you will hear a standard dial tone. DO NOT dial a number.
Once you hear the dial tone, Press the
TALK
/ END
and
#
VOL DN
keys at the exact same
time and then release. You will hear your dial tone decrease in volume and also
hear a number. Continue to press
TALK
/ END
and
#
VOL DN
keys at the same time and then
release until the desired volume is reached. The number will decrease with each
volume decrease. The phone will say “1” once the lowest volume is reached. When
nished press
TALK
/ END
to hang up the phone.
Resetting to Factory Defaults
STEP 1
To reset everything to factory defaults press the
VOL UP
and
#
VOL DN
keys at the exact
same time.
STEP 2
The phone will say “Factory defaults, press
1
to reset to default,
2
to cancel,
or
VOL UP
then
0
to disconnect.” To reset to default, press the
1
button on the
keypad. The phone will then say “Reset” and then shut o. At this point anything
that has been programmed in the phone is erased and reset to factory defaults.
Factory Defaults are as follows:
Voice Announcements - On
Call Cancellation - O
Immediate Two-Way Conversation - O
Maintenance Announcements - O
Ring Count - 1 Ring
Volume - Mid Level (4)
Emergency Phone Numbers - None
Site ID Message - None
Announcements - None
Talk Time - 180 seconds
Touch Tone ID - None
Installation
Line Connection
A.
Connect the telephone line wires to the “TELCO” pins on the circuit board using the
supplied connector. Check the phone line for a dial tone, touch tone capabilities and
noise. You can do this by using the
TALK
/ END
button. We suggest you call your emergency
numbers and have them call you back. This will verify touch tone lines, phone numbers
and line conditions.
B.
IMPORTANT! This step will save you time and unnecessary eld trips! Carefully
tape the shielding and any additional wires on the phone cable so they will not short
out the electronics or the telephone line at the circuit board. NOTE: GROUND THE
SHIELDING AT THE CONTROLLER OR SOURCE OF TELEPHONE LINE ONLY!
Power Requirements
A.
TELCO Voltage: 24-52 VDC
B.
TELCO Current: 23 mA
C.
External Voltage: 12-24 VAC/DC Isolated from Earth ground.
D.
External Current: 200 mA or Higher
E.
Battery Voltage: 9 VDC
F.
Battery Type: Rechargeable 150 mAh or higher
The S3 Communicator is not polarity sensitive.
Programming (Locally or Remotely)
To program Phone Numbers, Messages, Advanced Options and access Program Status press
the
PROG
MENU
button.
Programming Phone Numbers
STEP 1
Press
PROG
MENU
button on the keypad.
STEP 2
Press
1
for phone numbers.
STEP 3
Press
1
to program the rst number you want the phone to autodial. Press
2
for the second number you want the phone to autodial. Press
3
for the third
number you want the phone to autodial. If you only want one number programmed,
continue to the next step. If you want more than one number programmed, repeat
the following steps for each corresponding number slot.
STEP 4
Press
1
to program the number. Press
2
to review the number that was
previously programmed. Press
3
to delete the number.
#
VOL DN
to return to the
previous menu. Or
VOL UP
then
0
to leave programming mode. (continued on next
page)
