RapidMatch
™
XI Spectrophotometer
14
Not Properly Installed Properly Installed
Replacing the Light Seal
1. Using your finger nail or a small flat blade screwdriver (1), lift out one
edge of the light seal (2) from the recessed area and remove.
2. Orientate the new light seal over the recessed area around the
measurement port.
3. Press the new light seal into place until all 14 of the rubber tabs are
inserted properly and the light seal is lying flat.
16. Cleaning
The exterior of the instrument may be wiped clean with a cloth dampened in
water or mild cleaner. Dried paint on the exterior of the instrument can be
carefully removed using a paint scraper.
