RapidMatch
XI Spectrophotometer
9
Indicates the battery pack has a sufficient charge for a substantial
number of measurements.
Indicates the battery pack is low, but measurements are still possible.
Battery pack should be charged soon
Indicates the power adapter is plugged in and the battery pack is
charging.
Indicates the power adapter is plugged in and no battery pack is
installed.
11. Wi-Fi Option
This option is used to activate or deactivate Wi-Fi mode.
The Wi-Fi icon appears at the bottom of the display when the option is
activated in the Settings.
To activate, tap Wi-Fi and then tap the toggle switch. When the toggle switch is
in the right position the option is ON, and when the toggle switch is in the left
position the option OFF.
Once activated, the screen will show all available networks.
RapidMatch XI supports Wi-Fi standards IEEE 802.11 b/g/n in the 2.4GHz
Band. For maximum data transmission speed, channel bandwidth in the
settings of the wireless Access Point (AP) should be set to 40MHz or auto.
Please note that the AP will default back to 20MHz if the area is congested
with a high number of APs.
12. Navigating the Screen
The instrument features a graphical touch screen display. All functionality is
accessed directly through the screen.
Scrolling through Settings and Data
A scroll bar appears on screens when some settings or measurement data
cannot be accessed from the main view. A scroll bar on the right indicates
additional settings or data views are available. Swipe the screen up or down
to view the additional settings.
Left and right arrows at the top of the screen indicate that additional data is
available. Swiping the screen or tapping the arrows moves the screen to the
next available data screen. Swiping to the right or tapping the arrow returns
the screen to the previous view.
