Preparation
This section explains the preparation and resources required to install the Smart Card feature.
Configuration Checklist
The following items are required to complete the installation:
StatusSummary
1. Obtain the IP address or Host Name for each applicable Windows Domain Controller.
2. If Domain Controller Certificate validation is required, obtain the DC certificate for each ap-
plicable controller, including all intermediate certificates up to the root certificate.
Note
This procedure typically is required only for Smart Card.
3. If Online Certificate Status Protocol (OCSP) is available, obtain the IP address or Host Name
for the OCSP server.
4. If a software upgrade is required, obtain and install the required software release.
5. Mount the Smart Card Reader to the MFD and connect the USB cable to one of the rear ports.
Refer to Connect the USB Smart Card Reader to the MFD.
6. Install the Smart Card software Feature Enablement Key. Refer to Enter the Smart Card En-
ablement Key.
7. Configure Smart Card Authentication, the optional NTP, and the optional Alternate Login.
Refer to Configuring the Smart Card.
8. Installany required certificatesandconfigure validation settings. Refer to Configure a Security
Certificate.
9. Configure the MFD LDAPsettings. Refer to ConfigureAcquiring Logged-In User's Email Address.
2-1Xerox
®
AltaLink
®
Series
Smart Card Installation and Configuration Guide

Xerox AltaLink B8045 Specifications

General

Print Speed	Up to 45 ppm
Monthly Duty Cycle	Up to 200, 000 pages
Automatic Duplexing	Yes
Control Panel	10.1-inch color touchscreen
Functions	Print, Copy, Scan, Fax
Memory	4 GB
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Connectivity	Ethernet, USB, Wi-Fi
Scanner Type	Duplex Automatic Document Feeder
Copy Speed	Up to 45 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print
Print Resolution	1200 x 1200 dpi
Hard Drive	320 GB (optional)
