Phaser 3140/3155/3160 Printer Service Manual 9-17

Parts List

42. Roller-Feed 022N02421

43. Frame-Roller Exit Face Down —

44. Stopper-Lever_DR —

45. IPR-P-Ground_Drive —

46. Ground-Fuser —

47. IPR-P-Ground_TR —

48. Terminal-Con —

49. Terminal-Supply —

50. Terminal-CR —

51. IPR-P_Ground_Drive2 —

52. IPR-P-Ground_Guide Paper —

53. PMO-Gear_Exit_DRV16 —

54. PMO-Bushing Feed —

55. Cover Open Actuator —

56. Paper Tray Empty Actuator 120N00425

57.

57-1.

57-2.

Feed Actuator

Spring-TS

PMO-Feed Actuator

009N01653

022N02127

58.

58-1.

58-2

Manual Feed Actuator

Spring-TS

PMO-Actuator Manual

120N00532

009N01657

709N00007

59.

59-1.

59-2.

59-3

Pick Up Gear Unit

Spring-CS

PMO-Gear Pick Up A

PMO-Gear Pick Up B

—

60. PMO-Locker CST —

61. PMO-Plate Guide Deve_L —

62. PMO-Plate Guide Deve_R —

66. MEC-Terminal —

67. Terminal-CRUM —

68.

68-1.

68-2.

68-3.

68-4.

68-5.

Clutch Assembly

Spring-TS

Gear-Feed 1

Shaft-Feed

PMO-Collar Spring

PMO-Hub Clutch

005N01031

—

73. Photo-Interrupter 130N01574

74. IPR-P-Terminal CON —

75. Bracket-Bush_TR L —

Parts List 6.0 Frame (Continued)

ID No. Name/Description Part Number
