8-6 Phaser 3140/3155/3160 Printer Service Manual
Service Parts Disassembly
Maintenance Items and Consumables
Maintenance items include the Transfer Roller, Fuser, Pick Up Roller, and Tray. The
Print Cartridge is the only consumable item.
Print Cartridge
PL1.0.12
Caution
Do not touch the OPC drum or expose the Print Cartridge to light for more
than 5 minutes.
1. Open the front cover.
2. Pull the Print Cartridge out.
s3160-094
