Phaser 3140/3155/3160 Printer Service Manual 8-15
Service Parts Disassembly
Fuser Lamp
PL9.0.13
Turn the printer power Off and allow the Fuser to cool 30 minutes before
performing this procedure.
1. Remove the Fuser (page 8-11).
2. Release the 2 tabs on the right Fuser lamp cap and remove the cap.
Take care to not over flex the tabs as they can easily break.
