Phaser 3140/3155/3160 Printer Service Manual 3-19
Error Messages and Codes
Invalid Print Cartridge
If the Error LED is red (not blinking), the Print Cartridge may not be a genuine
Xerox print cartridge. Non-Xerox or Third Party Print Cartridges can cause
malfunctions, print-quality problems, and jam errors.
Initial Actions
• Cycle printer power.
• If problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Controller Board, PL 1.0.2
■ Print Cartridge, PL1.0.12
■ 3140 Controller Board Wiring
■ 3155 Controller Board Wiring
■ 3160 Controller Board Wiring
■ Map 1 - Controller Board (3140)
■ Map 2 - Controller Board (3155)
■ Map 3 - Controller Board (3160B/
3160N)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the Print Cartridge a genuine
Xerox cartridge?
Go to step 2. Replace with a
Xerox
cartridge.
2 Reseat the Print Cartridge and cycle
printer power.
Does the error persist?
Go to step 3. Complete.
3 Reseat CN9 on the Controller Board
(CN10 on the 3160) and cycle
printer power.
Does the error persist?
Go to step 4. Complete.
4 Check for +3.3V at CN9-4 (CN10-4
on the 3160).
Is +3.3V present?
Go to step 5. Replace the
Controller
Board
(page 8-51).
5 Replace the Print Cartridge
(page 8-6).
Does the error persist?
Replace the
Controller
Board
(page 8-51).
Complete.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3155 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	12000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 105 g/m²
Custom media sizes	76 x 127 mm - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003 Server/2008 Server, Vista, Mac OSX 10.3-10.6, Linux OS
Sustainability certificates	ENERGY STAR
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
