Phaser 3140/3155/3160 Printer Service Manual 9-27
Parts List
Parts List 9.0 Fuser
ID No. Name/Description Part Number
0. Fuser (110V)
Fuser (220V)
126N00332
126N00333
3. Screw-Taptype —
4. Screw-Taptype —
5. Screw-Taptype —
6. Screw-Taptype —
7. Washer Plain —
8. Washer Plain —
9. E-Ring —
10. Ring-CS —
11. Thermistor 130N01578
12. Thermostat 130N01490
13. Halogen Lamp
110V
220V
122N00269
122N00270
14. Spring TS —
15. Spring ES —
16. Spring TS 009N01657
17. RMO Rubber Exit —
18. PMO Bushing TX —
19. Guide Claw —
20. Spring ETC-Fuser Exit —
21. Spring ETC-PR(7300) —
22. Bush-PR High —
23. PMO-Exit Roller —
24. Harness-Fuser Joint —
25. Harness-Fuser AC —
26. Holder-Actuator —
27. Bush-M-HR R R2 —
28. Bush-M-HR L R2 —
29. Fuser Frame —
30. Input Guide —
31. Fuser Cover —
32. Fuser Dummy Cover —
33. Roller-M-Exit F/Up —
34. Pressure Roller 022N01611
35. Gear Fuser —
36. Heat Roller 022N02310
