Setting the ESC/P Mode 77
1 inch Skip
Sets whether or not to leave 1-inch space between pages.
The following options are available:
[Off] (default)
Does not leave 1-inch space between pages.
[On]
Leaves 1-inch space between pages. The printer skips a space between cut sheets
as it skips over the perforation on continuous-form paper.
NOTE: This feature is available when [Page Position] is set to [CSF Off].
Feed Position
Sets the position where printing starts by the length from the top edge of paper. The
options are [8.5 mm] (default) and [22 mm]. If setting this value in inches, select
[0.3"] (default) or [0.9"].
CR Functions
Sets how to handle CR command.
The following options are available:
[CR] (default)
Performs a carriage return only.
[CR/LF]
Performs a carriage return and then a line-feed.
0 Style
Sets the character style of "0" (zero).
The following options are available:
[0] (default)
Uses "0" without a slash (normal style zero).
[]
Uses "0" with a slash through it.
Specify Extension
Sets whether or not to enable the extension specified by selecting [Enable] or
[Disable] (default). When the extension is enabled, printing can be controlled using
text codes.
NOTE: An extended command is prefixed with an extender followed by command
identification data and parameter data (if necessary). An extension is the first 2 bytes of an
extended command (ESC (1BH in hexadecimal) followed by a ";" (semicolon or 3 BH in
hexadecimal)).
Extension
Sets the extension (first 2 bytes) of an extended command if you want to enable
printing by text codes. The codes between 0x21 and 0x7d are valid. The default is
[&%].
To Next Page
