5. Specify the scaling angle and position of the watermark:
• Select the scaling option that specifies the size of the picture in relation to the original image. Use the
arrows to scale the image in increments of 1%.
• To define the angle of the image on the page, specify the position option or to rotate the image left or
right by increments of 1, use the arrows.
• To define the location of the image on the page, specify the position option, or to move the image in each
direction in increments of 1, use the arrows.
6. Under Layering, select how to print the watermark:
• PPrriinntt iinn BBaacckkggrroouunndd: This option prints the watermark behind the text and graphics in the document.
• BBlleenndd: This option combines the watermark with the text and graphics in the document. A blended
watermark is translucent, so you can see both the watermark and the document content.
• PPrriinntt iinn FFoorreeggrroouunndd: This option prints the watermark over the text and graphics in the document.
7. Click PPaaggeess, then select the pages to print the watermark:
• PPrriinntt oonn AAllll PPaaggeess: This option prints the watermark on all pages of your document.
• PPrriinntt oonn PPaaggee 11 OOnnllyy: This option prints the watermark only on the first page of the document.
8. If you select a picture as a watermark, specify the lightness settings for the image.
9. Click OOKK.
ORIENTATION
Orientation allows you to select the direction that the page prints.
• For Windows, the Orientation tab is on the Document Options tab.
Note: The orientation setting in your application print dialog box may override the orientation options in the
print driver.
• For Macintosh, Orientation options are in the Print window.
The following options are available:
• PPoorrttrraaiitt: Orients the paper so that the text and images print across the short dimension of the paper.
• LLaannddssccaappee: Orients the paper so that the text and images print across the long dimension of the paper.
• RRoottaatteedd LLaannddssccaappee: Orients the paper so that the content is rotated 180 degrees and with the long bottom
side up.
Xerox
®
VersaLink
®
C71XX Series Color Multifunction Printer User Guide 153
Printing

Xerox VersaLink C7130 Specifications

General

N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	7 s
Print speed (black, normal quality, A3)	17 ppm
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	30 ppm
Optional connectivity	Bluetooth, Wireless LAN
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour /AirPrint
Internal memory	4096 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	41 dB
Sound power level (printing)	69 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (sleep)	0.4 W
Power consumption (standby)	94 W
Power consumption (printing)	520 W
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	129000 pages per month
Recommended duty cycle	0 - 7000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	4.4 s
Time to first copy (color, normal)	6.7 s
Copy speed (black, normal quality, A4)	30 cpm
Display	LCD
Control type	Touch
Product color	Blue, White
Display diagonal	7 \
Market positioning	Business
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	HP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan to	E-mail, Network folder, SMB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 431.8 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Included cartridge capacity (CMY)	9800 pages
Included cartridge capacity (black)	16100 pages
Total input capacity	620 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	520 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	130 sheets
Custom media width	88.9 - 297 mm
Custom media length	98.4 - 431.8 mm
Paper tray media types	Bond paper, Card stock, Heavy printing media, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
HDD capacity	320 GB
Browser supported	Microsoft Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages support	Multi

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	766.5 mm
Weight	62500 g
