7. Grasp the new staple cartridge by the orange handle, then insert the cartridge into the stapler assembly until it
clicks.
8. Close the finisher front door.
REPLACING STAPLES IN THE BOOKLET MAKER OF THE OFFICE FINISHER
CCaauuttiioonn:: Do not perform this procedure while the printer is printing.
1. Open the booklet maker side cover.
2. If the staple cartridges are not visible, grip the vertical panels at the left and right of the opening and slide the
panels to the center.
Xerox
®
VersaLink
®
C71XX Series Color Multifunction Printer User Guide 213
Maintenance
