Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-38
11. Install a new DADF Lifting Solenoid (PL
8.18, Parts List 8.1 WorkCentre 3345
SCANNER and DADF).
Does the error persist?
Install a new DADF
Separator Pad (DADF
Separator Pad).
Go to step 12.
Complete.
12. Enter dC330 Component Control, code
05-130 DADF Registration Sensor.
• If the Sensor changes state (is good), go
to step 13.
• If the Sensor does not change state (is
bad), install a new DADF Registration
Sensor (PL 8.2.13, Parts List 8.2
WorkCentre 3345 Lower DADF).
•If the Sensor changes
state (is good),
replace the DADF
PWB Section 4 (PL
8.1A .13, Parts List
8.1A WorkCentre
3345 DADF).
• If the error continues,
replace the Main
Board Section (PL 6.1.
7, Parts List 6.1
WorkCentre
3335/3345 Main).
• If the Sensor does not
change state (is bad),
replace the DADF
Feed/Registration
Sensor (PL 8.2.13,
Parts List 8.2
WorkCentre 3345
Lower DADF).
• If the error continues,
replace the DADF (PL
8.1A.13, Parts List
8.1A WorkCentre
3345 DADF) and then
the Main Board (PL
6.1.7, Parts List 6.1
WorkCentre
3335/3345 Main).
13. Enter dC330 Component Control, code
05-100 DADF Feed Sensor.
• If the Sensor changes state (is good),
replace the DADF Board (PL 8.1A.13,
Parts List 8.1A WorkCentre 3345 DADF).
• If the Sensor does not change state (is
bad), install a new DADF Feed Sensor (PL
8.2.24, Parts List 8.2 WorkCentre 3345
Lower DADF).
Enter dC330 Component Control, code
05-130 DADF Registration Sensor.
If the Sensor does not change state (is bad),
install a new DADF Registration Sensor (PL
8.2.13, Parts List 8.2 WorkCentre 3345
Lower DADF).
Does the error persist?
Go to step14. Complete.
14. Install a new DADF Board (PL 8.1A .13, Parts
List 8.1A WorkCentre 3345 DADF.)
Does the error persist?
Install a new DADF Drive
Unit (PL 8.5.8, Parts List
8.5 WorkCentre 3345
Drive DADF)
Complete.
Step Actions and Questions Yes No
To Next Page
