Maintenance
Xerox
®
WorkCentre
®
EC7836/EC7856 Color Multifunction Printer 201
User Guide
4. Each of the four printheads has its own cleaning tool. Slowly pull the LED printhead cleaner out until
the three dots are visible.
Note: The LED printhead cleaner does not detach from the printer.
5. Slowly push the LED printhead cleaner back into the printhead until it stops.
6. Repeat Steps 4 and 5 for each printhead.
7. Close the drum cartridge cover.
8. Turn the belt tension lever to the right to return it to the locked position.
9. Close the printer front cover.
